Full Color Video Led Outdoor Display Board With 1R1G1B / VGA , DVI Input Signal
1) System structure
2)Led Module
| Module Size(W * H) | 256mm*256mm | Pixel Configeration | 1R,1G,1B |
| Pixel Pitch | 16mm | Resolution(W*H) | 16dots*16dots |
| Pixel Density | 3906 dot / m2 | Driving Method | static Current |
3)Led cabinet
| Cabinet Size(W * H) | 1024mm*768mm | Module Qty | 20pcs |
| Cabinet Resolution(W * H) | 64dots*48dots | Cabinet Pixel | 4096 |
| Weight | 50kg/pc | Area | 1.23(m2) |
| Avarage Power Consumption | 600W/m2 | Max Consumption | 1000W/m2 |
4)Led Video wall technical parameter
| Operating Humility | 10% ~ 90% RH |
| Oprating Temprature | -30°C ~ +60°C |
| Optimal Viewing Distance | 10m-60m |
| Display Color | 1,070,000,000 |
| Gray Scale | 65536grade |
| Brightness control | 256grade |
| Frame Frequency | 60HZ |
| Refresh Speed | >3840HZ |
| Power Supply | 220V/50HZ |
| MTBF | ≥10,000hours |
| Life Span (50% brightness) | ≥100,000hours |
| Control Mode | synchronization with PC |
| Input Signal Format | VGA,DVI,RGBHV,PbPr(HDTV),Composite,S-Video,TV |
| Operating System | WINDOWS(98,2000,XP,Vista) |
Methods for Quality Assurance
a. Aging
1. 100% fully test
2. Condition: 72 hours with 256 grey level
b. Vibration Testing
Condition: 3-5 mins up and down in 5mm range
Factory Equipment
Wave Soldering Conveyor, PC Console, Wave Soldering Machine,
Automatic Glue- pouring Machine, Solder Paste Printing Machine,
Reflow Soldering Machine, Automatic Solder Paste Printing Machine,
Withstand Voltage Tester, Ground Resistance Tester,
Medium-speed Automatic SMT Machine, Super Mute Terminal Machine,
Automatic Wire Stripping Machine, Automatic Optical Inspection (AOI) Equipement.
Package
Flight case and Fumigation-Free wooden case
Competitive Advantage:
1. 2 years’ warranty with free repair service
2. 24/7 Hours online Remote Support
3. Solution and PCB design
4. Free factory training
5. Onsite installation instruction and regular inspection
6, Small order accepted.
